MDCE21_014 - TECHNICAL UPDATES

Introduction of the new MS3604 Secury Automatic multi-point lock, which offers the option of adding a fourth locking point. The new lock can be combined with latch bolt extensions or finishing bars. In particular, to a lock with a length of 1750 mm, it is possible to combine:

• Finishing bars MS3605 ( L=405mm) - MS3606 ( L=130mm)

• Top extensions fitted with latch lock MS3607 (L=300mm) MS3608 (L=500mm) - MS3609 (L=800mm)

The Secury Automatic multi-point lock can be used with the NC 65/75/90 HES DS-DL systems.

View the update for each system in the Doc Building app:

Material not kept in stock.

The catalogue CONCEALED DOOR CLOSERS of the “Accessories and design complements” family has been updated with the new ISM guide rail for double leaf doors.

The new guide rail with closing sequence control holds the active leaf in the waiting position until the passive leaf is closed.

Accessories for the new solution:

MA1519 - ISM guide rail for door closer MA1530 and MA1531

MA1529 - Mechanical hold-open with adjustable holding force

MA1548 – Shim for guide rail

MA1569 - Shim for guide rail

The door closer can be used on right-hand or left-hand swing doors with the following systems:

• NC 65 HES DS – Inward and outward opening

• NC 65 HES WS – Inward opening

• NC 65 HES WX – Outward opening

• NC 65 HES GD – Inward and outward opening

• NC 75 HES DS - Inward and outward opening

• NC 75 HES WS – Inward opening

• NC 75 HES WX – Outward opening

• NC 90 HES DS - Inward and outward opening

• NC 90 HES WS – Inward opening

• NC 90 HES WX – Outward opening

MA1519 and MA1529 Material not kept in stock.

Can be ordered from December

MA1548 e MA1569

Available on stock from December

NC 65 HES WS – INWARD OPENING

Introduced the new MA2881D/S lower sealing plug that allows the realisation of the two-leaf balcony door solution with low threshold also with T/Z profile. This and all the latest updates published in the appendix have been integrated into the catalogue.

MA2881D/S Available on stock from December

NC 75 HES WS - APERTURA INTERNA

NC 75 HES WS – INWARD OPENING

Introduced the new MA2881D/S lower sealing plug that allows the realisation of the two-leaf balcony door solution with low threshold also with T/Z profile.

Introduction of new profiles:

• Frame with external reinforcement for ribbon solution, NC17575 with 50mmreinforcement and NC17929 with 100mm reinforcement.

• NC17520 100 mm T-shaped frame

• NC17562 200 mm mid-transom

These and all recent updates published in the appendix have been integrated into the catalogue..

MA2881D/S, NC17929 and NC17562

Available on stock from December

NC17575 and NC17520

Material not kept in stock.

NC 90 HES WS – INWARD OPENING

New frame for ribbon solution NC13812.

These and all recent updates published in the appendix have been integrated into the catalogue.

Material not kept in stock.

NC 75 HES SLIM

New glazing beads for the NC 75 HES SLIM series:

NC16061 – 35 mm glazing bead

NC16062 –40 mm glazing bead

Available from January 2022

GLASS PARTITION

GLASS PARTITION

The ambidextrous MS5601 lock has been replaced by the new MS5601 Right or MS5601 Left specific versions. The new cards update and replace the previous ones dated 07/2020.

Item available on stock

The new METRA LIB 10 version is now available, harmonised according to the new streamlining of METRA Building product families. Important new features in the software are the introduction of the series managed in North America and the addition of dynamic glazing.

The access code is the same as in previous versions and will be automatically recognised for users who already have authorisation.
