  • Immagine del redattoreMetra Building

MDCE22_010 - TECHNICAL NEWS



The new POLIEDRA SKY TECH 50/60 CV products complete the evolution of METRA Building curtain wall systems.


Profiles and accessories available in stock from June 2022


























The new catalogue SUNBLADE of the "Shading systems" family has been published and can be consulted.

In the new catalogue the diagrams concerning the blade dimensioning have been updated, with the specification of the maximum length according to the wind pressure, and the new solution of fixing to the facade with MA2621 bracket directly fixed to the mullion has been inserted.

Obsolete solutions have been eliminated and the profiles for the Louvres and METRA Shutter systems have been moved to their respective catalogues.


MA2621 Available on stock from 2022.





The DOORS ON ESCAPE ROUTES catalogue of the METRA Building "Accessories and Design Complements" family has been updated and is now available for consultation.

The catalogue contains the following updates


  • The multipoint locks MS4066D/S-MS4068D/S-MS4069D/S-MS4071D/S have been replaced by new ambidextrous version. This solution will therefore be transversal to the two options and will keep the same code without the D/S specification.

  • New extensions already fitted with a locking latch and new finishing bars have been added to match the MS4066-MS4068-MS4069-MS4071 locks. In particular, it is possible to combine locks with a length of 1750 mm with:

    • Upper extensions with latch bolt:

      • MS4077 (L = 300 mm)

      • MS4078 (L = 500 mm)

      • MS4079 (L = 800 mm)

    • Finishing bars:

      • MS4080 ( L = 405 mm)

      • MS4081 ( L = 130 mm)


Non-stock material available on request








BOTTOM-HUNG WINDOW WITH CONCEALED HINGES - CASEMENT WINDOWS AND DOORS

Introduced the new solution using cremone bolts, latches and bottom hung arms from MR540i hardware with new concealed hinges as an alternative to the previous visible ones.

The new accessories for the new solution are:

  • MA9331 - Concealed hinge kit with sash supports

  • MA9332 - Additional sash support

  • MA9333 - Central cam set

The complete documentation for this new solution has been included in the HARDWARE FOR CASEMENT WINDOWS AND DOORS catalogue.

Material in stock








CLOSING SOLUTION FOR PROJECTING OPENINGS - POLIEDRA SKY 50 S

New locking solution for top-hung windows MA3979D/S Handle with off-set grip and 7 mm square spindleand MA7938D/S and bidirectional device for the POLIEDRA-SKY 50S series.

Material in stock








URANO WALL

The MA3907 and MA3908 accessories (support springs) have been eliminated in favour of fixing using the MA3914 support accessory.

The update sheets URANOWALL001 cancels and replaces the previous form dated 02/2020.

Item in stock
